TKB Studios · Formula wheel

Feel everyfraction.

Real carbon, a 4.3 inch display and six paddles.
Built for PC sim racing.

Preorder · €400
The TKB Studios wheel with a carbon faceplate, a central display, illuminated buttons, coloured rotary controls and carbon paddles behind the grips

MORE THAN
THE SURFACE.

A closer look

Scroll to open it up.
Paddles, spacer and every screw included.

Preparing the wheel

Hardware18 M4 screws, 14 standoffs.
Frontplate4 mm real carbon. Twill or forged.
Display4.3 inches, in the heart of the action.
ElectronicsThe connection behind every control.
EnclosureAluminium, with the six paddles and the spacer behind it.
Keep scrolling to separate the components See the details

At your fingertips

Every detail.
In your hands.

A clear view. Controls within reach.
A wheel designed around the way you drive.

Close view of the wheel's display and illuminated controls
Display
4.3inchCentral screen with LED lights
Backlit buttons
10Easy to find.
Ready to respond.
Central encoders
5Illuminated
rotary controls.
Funky switches
2More control
at your fingertips.
Thumb encoders
4Adjust without
breaking your flow.

Real carbon faceplate.
4 mm thick. Twill or forged, your choice.

PU grips.
Shaped around your hands.

Aluminium enclosure.
18 M4 screws and 14 standoffs tie the stack together.

23 shift lights.
Fifteen along the top, four each side.

Six paddles.
All carbon.

Four magnetic shifters and two clutches, each on its own module behind the grips. The magnets sit in plain sight, and every paddle is 4 mm carbon fibre.

Magnetic shifters
4Two on each side.
Clutch paddles
2One on each side.
Rear of the TKB Studios wheel: six carbon paddles on their modules around the spacer
Close view of the right-hand carbon paddles, their modules and visible magnets

The spacer is in the box.

It bolts to the back of the wheel and takes a quick release on the 6 × 70 mm pattern. Add the quick release for your wheelbase and the wheel fits it. The quick release itself is not included.

Paddles
6, carbon fibre, 4 mm
Shifters
4, magnetic
Clutches
2
Spacer
Included, 50 mm
Quick release
Not included

The whole
sheet.

Measured from the current CAD, November 2026. Small details can still change before production.

Controls

Backlit buttons
10
Rotary encoders
9: five centre, four thumb
Funky switches
2
Shifter paddles
4, magnetic
Clutch paddles
2

Display and lights

Display
4.3 inch
Active area
93.6 × 56.2 mm
Shift lights
23 LEDs: 15 top, 4 each side
Backlighting
Buttons and centre encoders

Materials

Front plate
Carbon fibre, 4 mm, twill or forged
Enclosure
Aluminium
Grips
Polyurethane (PU)
Paddles
Carbon fibre, 4 mm
Fasteners
18 M4 screws, 14 standoffs

Size

Width
292 mm
Height
177 mm
Depth
82 mm, knobs to paddles
Depth with spacer
95 mm
Weight
Measured on the first build

Mounting

Bolt pattern
6 × 70 mm
Spacer
Included, 50 mm long
Quick release
Not included

Compatibility

Platform
PC
Consoles
Not supported
Wheelbase
Any, with the quick release for it

Preorder

Before you
preorder.

Three things worth knowing first. The full list, shipping and payment are on the preorder page.

Read everything
Render of the Formula wheel from a three-quarter angleRender of the current CAD

Renders, not photos

Every image on this site is a render. The first production wheels do not exist yet, and your preorder is what builds them.

Close view of the red and blue encoder caps under the displayCap shapes can still change

Small details may change

Encoder caps, button caps, paddle outlines and finishes can still move before production. The layout, controls, display, materials and six paddles stay as listed.

The 50 mm spacer on the back of the wheel, between the paddle modules50 mm spacer, in the box

Bring a PC and a quick release

The spacer comes with the wheel. Add the quick release for your wheelbase, on the 6 × 70 mm pattern. Consoles are not supported.

Be there
the day it drops.

Preorders open in

Saturday 21 November 2026, 19:00 German time.

The date is planned, not locked. Shipping and the legal side are still being finished, and if anything moves, Discord hears first.
